Fully-Automatic
Food Service Window
- Speed of service is the key.
insulated model IFTSP-4860E offer exceptional speed and reliability to your drive-thru.
This unit is
perfect for any application demanding hands-free speedy service.
This unit features a built in air curtain to meet certain health codes and the
strict California regulations.
We can also offer
this unit with restricted openings for our California customers.
Each Electric slider is top-hung with no bottom track system. Each
unit comes with an offset in the Stainless Steel base preventing intrusion and
providing rain protection.
Operating sensors offered are the Photo-Electric Up-Eyes or the Thru-Beam
Horizontal Eye Bar.
With Up-Eye operation, the window is activated when the attendant stands in front of and over the 3 photo-eyes.
Thru-beam operation
requires the attendant to stand between an emitter and a receiver eye.
IFT-4860E models are fully insulated with 5/8" insulated glass.
MODEL
98Food Service Window
Dimensions: Service Opening on both models: 20 3/4"(w) x 29"(h)
Rough Openings on both models: 48"(w) x 60"(h)
MODEL
99Food Service Window
Product
Description SST-4035E - Security is the most important feature of this
window. The 15" reduced opening inhibits outside intruders from easily gaining
access to your business. This unit also has an electric auto-lock that locks the
window in place each time it closes. It comes standard with our thumb turn hook
lock and a night-time lock bar for added security.
Each Electric slider is top-hung with no bottom track system. Each unit
comes with an offset in the Stainless Steel base preventing intrusion and
providing rain protection.
Operating sensors offered are the Photo-Electric Up-Eyes or the Thru-Beam
Horizontal Eye Bar. With Up-Eye operation, the window is activated when the
attendant stands in front of and over the 3 photo-eyes. Thru-beam operation
requires the attendant to stand between an emitter and a receiver eye.
Dimensions:
Service Opening:
15" (w) X 29" (h)
Rough Opening:
48 3/8" (w) X 52 3/8" (h)
SFM-54E
Bi-parting model FM-54E mounts flush to the exterior wall. With a Service Opening of 18 1/2" (w) x 26 5/8" (h) and a large counter space, this model will enhance your overall operation.
Operating sensors offered are the Photo-Electric Up-Eyes or the Thru-Beam Horizontal Eye Bar. With Up-Eye operation, the window is activated when the attendant stands in front of and over the 3 photo-eyes. Thru-beam operation requires the attendant to stand between an emitter and a receiver eye.
Counter Space: 53 1/2" (w) x 12" (d).
Service Opening: 18 1/2" (w) x 26 5/8" (Rough Opening: 54"(w) x 40 1/2"(h)
MODEL
100Food Service Window
MODEL
101Food Service Window
The bi-parting projected window model PW-54E provides a three-sided panoramic view with one of the largest counter spaces offered on a drive-thru window.
A drip rail and an offset in the stainless steel counter prevent water from leaking into the interior.
Operating sensors offered are the Photo-Electric Up-Eyes or the Thru-Beam Horizontal Eye Bar.
With Up-Eye operation, the window is activated when the attendant stands in front of and over the 3 photo-eyes. Thru-beam operation requires the attendant to stand between an emitter and a receiver eye.
Counter Space: 53 1/2"(w) x 20"(d)
Service Opening: 18 1/4"(w) x 31 1/2"(h)
Rough Opening: 54"(w) x 40 1/2"(h)
Flush mount model
MODEL
102Food Service Window
operates with two bi-parting "top-hung" doors allowing for faster speed of service at the drive-thru window.
With an overall depth of 21", the stainless steel counter provides both inside and outside shelf space for your attendants and customers.
Operating sensors offered are the Photo-Electric Up-Eyes or the Thru-Beam Horizontal Eye Bar. With Up-Eye operation, the window is activated when the attendant stands in front of and over the 3 photo-eyes. Thru-beam operation requires the attendant to stand between an emitter and a receiver eye
Counter Space: 42"(w) x 11"(d) Service Opening: 15 1/2"(w) x 27"(h)
Rough Opening: 42 1/2"(w) x 40 1/2"(h)
MODEL
103Food Service Window
Speed of
service is the key. Bi-parting windows operate nearly twice as fast as
single-sliders!
This flush mount fully-automatic window glides smoothly on a top hung rail
system.
Each unit comes with an offset in the Stainless Steel base preventing
intrusion and providing rain protection.
Operating sensors offered are the Photo-Electric Up-Eyes or the Thru-Beam
Horizontal Eye Bar.
With Up-Eye operation, the window is activated when the attendant stands in front of and over the 3 photo-eyes.
Thru-beam operation
requires the attendant to stand between an emitter and a receiver eye.
This unit can be glazed with 5/8" insulated glass.
Custom powder coat colors available
Reduced service openings for areas requiring less than 432 sq. inches
Various shades of tinted glass available
OPTIONAL exterior shelf
MODEL
104Food Service Window
New to the industry! This 72" wide bi-parting electric slider has one of the largest service openings in the drive-thru arena.
With a generous 30" (w) x 30" (h) opening, you can effectively operate with two workers in one window or pass large items such as dry cleaning, large pizza boxes, auto parts, etc..
This window comes standard with a push button opening/closing device, however, our thru beam sensors or our patented "up-eyes" sensors can be used to operate this unit.
We also make a manual, self-closing version of this window
Food Service Window
Speed of service is the key. Models offer exceptional speed and reliability to your drive-thru.
This unit is perfect
for any application demanding hands-free speedy service.
Each Electric slider is top-hung with no bottom track system. Each unit
comes with an offset in the Stainless Steel base preventing intrusion and
providing rain protection.
Operating sensors offered are the Photo-Electric Up-Eyes or the Thru-Beam
Horizontal Eye Bar. With Up-Eye operation, the window is activated when the
attendant stands in front of and over the 3 photo-eyes. Thru-beam operation
requires the attendant to stand between an emitter and a receiver eye.
fully insulated with 5/8" insulated glass.
Dimensions: Service Opening on both models: 20 3/4"(w) x 29"(h)
Rough Openings on both models: 48 3/8"(w) x 41 3/8"(h)
MODEL
105Food Service Window
Other Models of Food Service Windows
Question's: 915 - 240-4747
