Large Vehicle Bomb Detection
In the continuing war against terrorism,
Large Vehicle
Bomb Detection System (LVBDS) is the answer to one of the terrorists'
greatest threats - MASS DESTRUCTION.
LVBDS is an integrated system solution addressing the need for detection
of large vehicle-bombs with a high vehicle throughput rate.
The LVBDS combines an automated touch less vehicle sampling system with
patented chemical detection product and an intuitive
icon-driven integrated system user interface.
Fully automated for continuous
operation, user-friendly and highly reliable, LVBDS can be adapted to suit
site-specific architectural and threat detection requirements
LVBDS is effective in a wide range of applications:
Security facilities
Military installations
Transportation terminals
Industrial sites
Security establishments
Religious sites
Embassies
Office towers
Nuclear facilities
.... Worldwide
Vehicle Size
Standard maximum dimensions:
2.20 m W x 2.25 m H x 8 m long
7.21 ft. W x 7.37 ft. H x 26.2 ft. long
Larger sizes available for specific applications with larger objects
Throughput Time
Typically less than one minute (depending on operational configuration)
Explosives Detection Capability
Standard compounds: TNT, NG, AN, EGDN, o-MNT, p-MNT, DMNB
Dynamite, smokeless powder & other commercially available explosives
*ICAO marker compounds
Analytical Unit Sensitivity
Vapors - parts per trillion
Particulates - nanograms to picograms
Components
GC / IMS chemical detection units (2)
Air compressor
Vacuum blowers (2)
Air receivers (2)
Vehicle scanning facility consisting of:
- Tracks, vehicle guide rail set and treadle
- Moveable scanning arch
Electrical and control panels (2)
Boom assembly
System integration computer; industrial grade
Electronics rack
Operator Features
Audible and visual alarm annunciation
Graphical interface with animation of system operation
Integrated operation, scanning system, doors, optional sub-systems
Fault condition alarms for all equipment
Power Requirements
Standard Equipment:
72 kVA, 3 phase, 575 VAC, 60 Hz (includes 2 kVA conditioned power)
10 kVA, 1 phase, 115 VAC, 60 Hz conditioned, UPS recommended
Optional voltage/frequency powering available:
400/230 VAC, 50 Hz
208/115 VAC, 60 Hz
Space Requirements
Operator room, local or remote, 9 m² (100 ft.²)
Equipment room, 16 m² (172 ft.²), 3.6 m ceiling clearance adjacent to scanning
area
Vehicle scanning area, 5 m wide, 11.5 m long, 4.5 m ceiling clearance
(16.4 ft. W, 37.7 ft. length, 14.8 ft. ceiling clearance)
Environmental Requirements
Operator room, typical indoor office environment
Equipment room, controlled, 25°C ± 5°C
Vehicle scanning area, 5°C to 40°C
System Optional Components and Design Services
Integrated CCTV camera system
Digital video recording system
Integrated vehicle tag-based access control system
Integrated weigh scale
Architectural/system design support
Vehicle containment options
Blast containment options
Touch-screen operation
Health Hazards
None
Environmental Impact
None
CALL for more information.
This product requires a physical site survey to determine the cost of the installed unit.
