Welcome to

Where The World Can Find Beltrac!!!

(12174 bytes)

Beltrac^Ž is Choice!
` Beltrac public guidance system gives you more to choose from. Lots more! More styles, more standard features and options, more colors, textures and finishes, and even more ways to meet budget requirements.

Beltrac^Ž is Safety.
` Beltrac public guidance system is designed and engineered to protect your public with a broad range of innovative and effective safety features.

Beltrac^Ž is Innovation.
Every element of ` Beltrac public guidance system is the result of our ongoing, comprehensive R & D program. Our goal is to meet "real people" requirements with superior solutions.

Beltrac^Ž is Value.
` Beltrac public guidance system is known for innovation, safety features and smart design solutions. These are the keys to Beltrac`s day-after-day value!

Beltrac^Ž is Safety.

` Beltrac public guidance system is designed and engineered to protect your public with a broad range of innovative and effective safety features.

Beltrac sign frames feature smooth radius corners that eliminate sharp edges near your customers. Our newly designed sign frames are also aesthetically pleasing to enhance your corporate image.

Post Design

The post is constructed of one continuous piece, attached to a weighted steel base. The retractable belt mechanism is completely concealed within the post. No additional attachment for belt mechanism is required. The retractable belt mechanism may be easily field replaced by the user.

POST TO BASE ASSEMBLY: Each Beltrac utilizes an innovative patent pending, connection for assembly of post to base. This rigid, heavy-duty connector enables the user to assemble or disassemble a post or a whole queuing line with a simple turn of a key

Every element of ` Beltrac public guidance system is the result of our ongoing, comprehensive R & D program. Our goal is to meet "real people" requirements with superior solutions.

SLOW RETRACTING BELT FEATURE: The Beltrac mechanism is equipped with a unique, centrifugal belt-braking system, allowing the belt to retract slowly and safely if accidentally released.

BASE COVERS: Metal cover plate to match post finish.
• Durable, scratch resistant plastic cover plate.

RUBBERIZED BASE BOTTON: Each post includes a standard, factory applied, rubberized base to protect flooring from damage.

AUTOMATIC BELT LOCKING MECHANISM: A single metal lock is engineered to create an automatic belt locking system that prevents accidental release of belts. In addition, this option is uniquely designed to lock signs and accessories to posts.

Dovetail Belt Receiver

Each post has four (4) vertical "dovetail" shaped grooves. The belt extends from one groove, while the other three (3) may be used to accept belt ends or other accessories. The belt end is constructed of solid plastic and contoured to fit into the "dovetail" shaped grooves.

4-Way Connection
The posts are equipped with a standard 4-way post connection, allowing each post to deliver one (1) belt while simultaneously receiving three (3) belts. The connections are "imbedded" into the post to eliminate breakage.

WARRANTY:

5 years on post
3 years on mechanism

Beltrac^Ž 3000 Dimensions and Specifications

Post Height	40 inches
Weight	28 lbs.
Post Material	Aluminum
Finish	Anodized, Lido-Tone^Ž
Base Cover	Metal or Plastic
Slow Retracting Belt	Yes
Belt Length	7 ft
Beltloc^™	Option
4-Way Belt Connections	Yes
Base Diameter	14 inches
Rubberized Base	Yes
Signage Ready	Yes
Outdoor Usage	Option
